| Specification | |||
| RT-SL 160 | RT-SL 300 | ||
| Thread Type | Availale Spairal Shank/ Ring Shank |
Availale Spairal Shank/ Ring Shank |
|
| Prouduction Speed | 2,000 ~ 500NPM | 500 ~ 200 NPM | |
| Nail Size | Length | 75 ~ 160mm | 160 ~ 300mm |
| Diameter | Ø 1.20 ~ Ø 4.87mm | Ø 1.20 ~ Ø 4.87mm | |
| Bowl Feeder | 40″ | 40″ | |
| Thread Length Range(*) | 3″(76mm) | ||
| Tooling Size | 7″/5.5″ Χ 3″(178/140~76mm) | ||
| Main Motor | 15HP(12Kw) | ||
| Electric Power | 15KVA, 3 Phase/220V/50~60Hz | ||
| Space Required | 5.9L x 3.9W x 6.6H Feet (1,800L x 1,200W x 2,000H mm) | ||
| Weight | 4,400 Lbs (2,000 Kg) | ||
Precise Feeding Planetary Thread & Form Rolling Machine
40″ Vibratory Feeder Bowl, ATAC Drive by Motion Sensor
– Nail Inserting by Armed Finger with CAM Drive.!
– Full Feature Vector Drive by-Heavy Duty Spiral Bevel Gear
– Cooling apparatus for dies block guarantee extremely long life of dies.
– Easy Setup / Easy Maintenance
